Reusing domain objects to create query specifications

4 Minutes reading time

Problem

Often you need to create query specifications to retrieve data from persistent memory. One of the following patterns is most likely used:

Bind Entity or Service with a distinct Query Object to the repository. A Service creates a distinct query object, passes it to the repository. Here the query object is translated to a Hibernate or JPA Criteria or HQL Statement and finally executed against the database.

Pros:

  • For every use case a distinct Query Object can be created. This helps a lot to encapsulate domain logic.

Cons:

  • The query object and the Entites or Aggregates can be quite redundant, if you use techniques like Query by example. Also, those query objects cannot be reused for other use cases. This avoids a “Generic” Repository interface.

Bind Entity or Service with specification to the repository. A Service creates a query Specification and passes it to the repository. Here the query object is translated to a Hibernate or JPA Criteria or HQL Statement and finally executed against the database.

Pros:

  • A specification is a more general form of query object. It helps to keep the Repository interface lean.

Cons:

  • Specifications can be tricky to implement.

Use Hibernate Criteria or HQL directly. A Service creates a Hibernate Criteria, passes it as a Query Object to the Repository, and it is executed against the database,

Pros:

  • No pros. This is just ugly.

Cons:

  • Criteria or HQL are referencing Classes or even properties directly. This makes it a possible problem for refactoring. You can use the JPA2 Meta Model to avoid this problem, but this also introduces a new concept which is more likely just a workaround.

Solution

Why not use reuse the domain objects to create a query specification or query object? I mean to reuse the structure and behavior. We are already doing something like this to create Mock Objects with EasyMock/PowerMock or Mockito. Why not do the same thing to create query specifications?

Pros:

  • The Repository will become a lean interface, just accepting a general query specification and finder methods to retrieve Entites by identifier. A large amount of search use cases can be unified.

Cons:

  • Some use cases cannot be modeled this way, for instance projection queries or count/aggregate functions.

Project Mogwai provides a library called Mogwai SpecificationBuilder to do it just this way.

Example:Given are the following classes:

public class Person {

    private String name1;
    private String name2;
    private String name3;
    private long sallary;

    private Address address;

    public Person() {
        address = new Address();
    }

    public String getName1() {
        return name1;
    }

    public void setName1(String name1) {
        this.name1 = name1;
    }

    public String getName2() {
        return name2;
    }

    public void setName2(String name2) {
        this.name2 = name2;
    }

    public Address getAddress() {
        return address;
    }

    public void setAddress(Address address) {
        this.address = address;
    }

    public String getName3() {
        return name3;
    }

    public void setName3(String name3) {
        this.name3 = name3;
    }

    public long getSallary() {
        return sallary;
    }

    public void setSallary(long sallary) {
        this.sallary = sallary;
    }
}

public class Address {

    private String zipCode;
    private City city;

    public Address() {
        city = new City();
    }

    public String getZipCode() {
        return zipCode;
    }

    public void setZipCode(String zipCode) {
        this.zipCode = zipCode;
    }

    public City getCity() {
        return city;
    }

    public void setCity(City city) {
        this.city = city;
    }
}

public class City {

    private String name;

    public String getName() {
        return name;
    }

    public void setName(String name) {
        this.name = name;
    }
}

Use case 1: a simple search for all Person entities with a given Name1 and Name2

ConjunctionSpecification<Person> theSpecification = new ConjunctionSpecification<Person>(new Person());

Person thePerson = theSpecification.root();
thePerson.setName1("SuchString1");
thePerson.setName2("SuchString2");

will result in the following query string:

(name1 = {SuchString1}AND name2 = {SuchString2})

Usecase 2: a simple search for all Person entities with a given Name1 and nor a given Name2

ConjunctionSpecification<Person> theSpecification = new ConjunctionSpecification<Person>(new Person());

Person thePerson = theSpecification.root();
thePerson.setName1("SuchString1");
theSpecification.notEquals().setName2("SuchString2");

will result in the following query string:

(name1 = {SuchString1} AND name2 != {SuchString2})

Usecase 3: a like search for all Person entities

ConjunctionSpecification<Person> theSpecification = new ConjunctionSpecification<Person>(new Person());

Person thePerson = theSpecification.root();
thePerson.setName1("SuchString1");
theSpecification.like().setName2("%lala%");

will result in the following query string:

(name1 = {SuchString1} AND name2 LIKE {%lala%}

Usecase 4: traversing aggregated Entities

ConjunctionSpecification<Person> theSpecification = new ConjunctionSpecification<Person>(new Person());

Person thePerson = theSpecification.root();
thePerson.getAddress().getCity().setName("Berne");

will result in the following query string:

(address.city.name = {Berne})

Under the hood

Mogwai SpecificationBuilder creates CGLib proxies for domain objects. These proxies capture the invoked behavior on the domain objects and creating a corresponding query specification. The proxies also handle object graph navigation.

Conclusion

Mogwai SpecificationBuilder helps to create query specifications for a large amount of use cases without introducing additional concepts. Recorded query specifications can be converted into Hibernate Criteria or HQL statements in a very generic and reusable way. This helps to keep the Repository interface clean and is also very refactoring safe. For further investigations, you can also consult the Query DSL Project. It combines a kind of JPA2 Meta model with query specifications.
